How to configure a payment workflow in InterWeave without code?


How to Configure a Payment Workflow in InterWeave—Without Writing Any Code
A Step-by-Step Guide to Building Secure, Automated Payment Flows
With InterWeave SmartSolutions, businesses can set up powerful, PCI-compliant payment workflows between systems like Salesforce, Authorize.net, QuickBooks, and others—without any coding. Everything is done through an intuitive web-based interface using configurable profiles and rules.
Here’s how easy it is to configure a fully automated payment workflow using InterWeave.
Use Case Example
Goal: Automatically process a payment through Authorize.net when an Opportunity in Salesforce is marked “Closed-Won,” then record the payment in QuickBooks and update the CRM.
Step-by-Step: No-Code Payment Workflow Setup
Step 1: Create a Payment Profile
- Log in to your InterWeave SmartSolutions portal
- Go to Profile Manager → Create New Profile
- Select the systems you want to connect:
- Source: Salesforce
- Action: Trigger Payment
- Target: Authorize.net (or Stripe, Intuit Payments, etc.)
- Name your profile: e.g., Salesforce-to-AuthorizeNet-Payment
Profiles are reusable templates that define the logic and rules behind the workflow.
Step 2: Set Workflow Triggers
- Define when the payment should initiate:
- Trigger on: Opportunity Stage = Closed Won
- OR checkbox field: “Ready for Billing” = true
- You can add filters like:
- Opportunity Amount ≥ $100
- Payment Method = Credit Card
No need for Apex triggers or scripting—this is all dropdown-selectable.
Step 3: Map CRM Fields to Payment Gateway
- In the Field Mapping tab, configure:
- Opportunity.Amount → Transaction Amount
- Contact.Email → Customer Email
- Stored Token (from payment portal) → Payment Method
- You can also use:
- ACH or credit card options
- Customer-specific tokens securely stored in Authorize.net
Secure PCI-compliant tokenization ensures no card data is stored in your CRM.
Step 4: Configure Post-Payment Actions
- Update Salesforce:
- Mark Opportunity as “Paid”
- Add Payment ID to custom field
- Trigger “Thank You” email via Salesforce Flow
- Send to QuickBooks (optional):
- Sync payment details to the related QuickBooks Invoice
- Mark invoice as Paid
- Reflect updated AR balance
- Alert your team (optional):
- Trigger email or Slack message on payment success/failure
All actions are chosen from dropdowns and logic builders—no scripts required.
Step 5: Test & Activate
- Run in Test Mode with sandbox data
- Review logs and success/failure reports in the InterWeave Dashboard
- Switch profile status to Active when ready
Example Workflow Summary:
Salesforce Opportunity Closed-Won
InterWeave initiates Authorize.net payment
Payment processed (real-time)
Salesforce updated + QuickBooks invoice marked paid
Customer receives receipt and confirmation
Why It Works (Without Code)
| Feature | Benefit |
| Profile-Based Logic | Reusable and customizable workflows |
| No-Code Interface | Configure everything through dropdowns, rules, and field maps |
| Secure & Compliant | Built-in tokenization and audit logging |
| Real-Time Sync | Seamless updates across CRM, accounting, and payment platforms |
| Scalable | Supports high transaction volumes and recurring payments |
Advanced Options Available
- Recurring Billing Profiles
- Multi-currency & multi-gateway setups
- Self-service Customer Payment Portal with secure token storage
- Declined payment retry logic and alerts
